• 10 user selectable output ranges to choose from:
 0-10ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm,
 0-.500%, 0-1%, 0-5%, 0-10% and 25%
 The user selection of an output range simultaneously
 controls the two alarms, the analog output and the data
 logger so that all 4 functions operate on the same range
• Digital display: High resolution 3 ½ digit LCD. Reads full
 scale from 0.00ppm to 25.0% independently of output
 range selection
• Alarms: 2 fully adjustable oxygen concentration alarms
 Dry contacts 5A. @24VDC/115VAC
• Alarm delays: Programmable from 0-300 minutes
• Alarm hold off: Programmable from 0-120 minutes
• Isolated analog output signal: 1-5VDC or 4-20mA
 Represents the output range selected: 0-10ppm, 0-50ppm,
 0-100ppm, 0-500ppm, 0-1000ppm, 0-.500%, 0-1%, 0-5%,
 0-10% and 25%
• Data logger: Logs data for 15 days @ 1 minute intervals,
 30 days @ 2 minute intervals, etc. Represents the output
 range selected: 0-10ppm, 0-50ppm, 0-100ppm, 0-500ppm,
 0-1000ppm, 0-.500%, 0-1%, 0-5%, 0-10% and 25%
• Power requirements: 10-28VDC/ 115VAC; <70mA. @
 12VDC non heated; <24W @12VDC with heated option
• Minimum detection: 50ppb of oxygen
• Repeatability: +/- 1% of range or +/- 0.2ppm of oxygen,
 whichever is greater
• Operating temperature range:
 25 to 115˚ F non-heated; -20 to 115˚ F heated option
• Diurnal temperature specification:
 < +/- 3 % of scale over temperature range
• 90% upscale response times: 10ppm – 25% <10 seconds
 0-10ppm < 25 seconds. Typical downscale response:
 1 minute exposure to air down to 10ppm: < 15 minutes
• Area Classification: Approved by CSA International to
 UL and CSA standards as meeting requirements for
 Class 1, Div. 1, Groups B,C,D with a flammable gas sample
• Inlet gas pressure: 0.5 to 150psig
• Gas connections: ¼” 316 S.S. compression fittings
• Wetted parts: 316 S.S. fittings, electroless nickel plated
 cellblock, gold plated contacts, acrylic flow meter and
 Viton O-rings
• Unaffected by changes in flow rate from 0.1 to
2.0 SCFH
• Mounting: Wall mount or 2.0” pipe
• Dimensions: 13.0”W x 9.5”H x 5.0”D
• Weight: 16 lbs.
