• 10 user selectable output ranges to choose from:
 0-10ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm,
 0-.500%, 0-1%, 0-5%, 0-10% and 25%
The user selection of an output range simultaneously
controls the analog output so that both functions
operate on the same range
• Digital display:
 High resolution 3 digit LCD. Reads fullscale from
  0.0ppm to 25.0% independently of output range selection
• Isolated analog output signal :
 1-5VDC or 4-20mA
 Represents the output range selected: 0-10ppm, 0-50ppm,
 0-100ppm, 0-500ppm, 0-1000ppm, 0-.500%, 0-1%, 0-5%,
 0-10% and 25%
• Power requirements:
 10-28VDC <50mA. @ 12VDC
• Minimum detection:
  50ppb of oxygen
• Repeatability:
 +/- 1% of range or +/- 0.2ppm of oxygen, whichever is greater
• Operating temperature range:
  25 to 115˚ F
• Diurnal temperature specification:
< +/- 3 % of scale over temperature range
• 90% upscale response times:
 10ppm – 25% <10 seconds; 0-10ppm < 25 seconds
 Typical downscale response: 1 minute exposure to air
 down to 10ppm: < 15 minutes
• Area Classification:
 Designed to meet requirements for
 Class 1, Div. 2, Groups C,D applications
• Inlet gas pressure:
  0.5 to 150psig
• Gas connections:
  ¼” 316 S.S. compression fittings
• Wetted parts:
 316 S.S. fittings, electroless nickel plated
 cellblock, gold plated contacts, acrylic flow meter and
 Viton O-rings
• Unaffected by changes in flow rate from 0.1 to
2.0 SCFH
• Mounting:
 Wall mount or 2.0” pipe
• Dimensions:
 7.0”W x 6.5”H x 4.5”D
• Weight:
 6 lbs.



When the application requires, we can provide one of our
patent pending H2S resistant oxygen sensors (up to 500ppm
 H2S  exposure for its warranted life) to meet your needs.
This break-through sensor technology eliminates the need
for maintenance intensive H2S scrubbers
