Sensor
Photodiode
2 Analogue outputs
0(4) - 20 mA linear, scaleable
Load
max. 500 Ω
Voltage input
0 - 10 V linear, scalable
2 switching outputs
Open Collector 24 V, ≤ 30 mA
2 switching inputs
24 V
Data communication
• USB
• RS-485
(integrated user interface)
LED display
4-digit (digit height 8 mm)
Measurement uncertainty
1 % of temp. reading
(at ε = 1 and T
 = 23 °C)
Repeatability
2 K
Resolution
Current output
0.2 K + 0.03 % of selected range
Temperature reading
1 K
USB / RS-485:
0.1 K in terminal mode
Operating voltage:
24 V DC +10% / -20%
Current consumption
≤ 135 mA
≤ 150 mA with laser sighting
≤ 175 mA with video camera
Ripple ≤ 200 mV
Permissible humidity
95 % RH max.
(non-condensing)
Ambient temperature
0 — 65 °C (without cooling)
Storage temperature
-20  — +80 °C
Housing material
Stainless steel
Protection
IP65 according to DIN 40050
Connectivity
M14 thread, 8-pin connection
Weight
approx. 0.9 kg


Special Accessories

Oscillating mirror PZ 20/X
Illumination ring PZ 10/P
Display unit DA 230
Controller URE 422

*적용분야 :

 Crystal pulling ,Coke oven ,Wire mill ,Coil coating ,Pipe manufacturing , Incinerator , Rolling mill ,
 Blast furnace / stove dome , Power plant , Hot-dip coating ,Rotary kiln , Preheating furnace ,Glass   manufacturing , Lime production
