Temperature ranges
 As per table of models
Resolution
 Display: 1 K
 USB port: 0.1 K
Temperature coefficient
 ≤ 0.05 %/K
 Referenced to 23 °C
LED display (7 segments)
 4-digit; (digit height 8 mm )
Power supply
 Rechargeable battery pack
 Mains adapter (continuous operation)
Battery life
  Approximately 15 hours
(based on continuous  operation at Ta = 23°C)
Permissible humidity
 95 % r.h. max. (non-condensing)
Ambient operating temperature
 0 ... +50 °C
Storage temperature
 -20 … +60°C
Material
 housing: aluminium
 handle: polyamide
Protection
 IP 40 according to DIN 40050
Weight
 approx. 1.1 kg
Sighting
  True-sided through-the-lens
sighting, parallax free, target spot
indicator, diopter compensation,
polarizing filter
Diopter range
 -3 … +1 diopters, adjustable
Digital output
 USB
Buzzer alarm
 Highly configurable
Tripod
 3/8“ for housing and handle
Memory modes
 Current, maximum, average values
ATD function
  Automatically identifies the target
and detects its temperature

Protective glass 70146
Supplementary lens
PZ 20/O
Laser module PA 20/Q

*적용분야 -  Metals, ceramics at high temperature
• For metallic surfaces, ceramics, liquid glass at high temperature range

Application Note 자세히보기
1. 용광로

2. 유리
