Temperature range: 750  -  2400 °C
Sensor: Photo diode
Spectral sensitivity: 0.95 / 1.05 µm
2 Analogue outputs: 0(4) - 20 mA linear, switchable, scalable
Load: max. 500
2 Switching inputs / outputs
 Open Collector 24 V, £ 30 mA
Date communication:
 • USB
  • RS 485
(integrated menu-driven user interface to set parameters and
transmit data to a PC)
LED Display: 4-digit (digit height 8 mm)
Response time t98: 10 ms
Measurement uncertainty: 1 % of temp. reading, at least 4 K
(at e = 1 and Ta = 23 °C)
Repeatability:  2 K
Current output: 0.2 K + 0.03 % of selected range
 Display: 1 K
USB / RS 485: 0.1 K in terminal mode
Temperature coefficient:
 ≤ 0.05 %/K of temp. reading [°C]
(deviation to 23 °C)
Power requirement: 24 V DC +10% / -20%
Current input
  ≤ 135 mA
  Ripple ≤ 200 mV
Permissible humidity:95 % r.H. max.  (noncondensing)
Ambient operating temperature: 0  -  65 °C (without cooling)
Storage temperature: -20  -  +80 °C
Housing: Stainless steel
Protection rating: IP65 according to DIN 40050
Connectivity:
8-pin connection with screw thread

* 악세사리 및 소모품

* 적용분야

용해로, 용광로, 전로, 보온로,

먼지, 스팀등 악조건에서의 정밀 온도 측정


Application Note 자세히 보기

1. 용융 금속 - 캐스팅 채널


2. 용융 금속 - 용광로, 디캔팅, 캐스팅머신
